LTI ROM creation and simulation

This example shows how you can use PyAEDT to create a Linear Time Invariant (LTI) ROM in Twin Builder and run a Twin Builder time-domain simulation. Inputs data are defined using Datapairs blocks with CSV files.

Keywords: Twin Builder, LTI, ROM.

Perform imports and define constants

Perform required imports.

import datetime
import os
import subprocess
import tempfile
import time

import matplotlib.pyplot as plt
from ansys.aedt.core import TwinBuilder, downloads
from ansys.aedt.core.application.variables import CSVDataset

Define constants

AEDT_VERSION = "2024.2"
NUM_CORES = 4
NG_MODE = False  # Open AEDT UI when it is launched.

Set paths and define input files and variables

Set paths.

training_data_folder = "LTI_training_data.zip"
temp_folder = tempfile.TemporaryDirectory(suffix=".ansys")
input_dir = downloads.download_twin_builder_data(
    training_data_folder, True, temp_folder.name
)

Download data from example_data repository

data_folder = os.path.join(input_dir, "LTI_training")

Unzip training data and parse ports names

downloads.unzip(os.path.join(input_dir, training_data_folder), data_folder)
ports_names_file = "Input_PortNames.txt"

Get ports information from file

def get_ports_info(ports_file):
    with open(ports_file, "r") as PortNameFile:
        res = []
        line = PortNameFile.readline()
        line_list = list(line.split())
        for i in range(len(line_list)):
            res.append("Input" + str(i + 1) + "_" + line_list[i])

        line = PortNameFile.readline()
        line_list = list(line.split())
        for i in range(len(line_list)):
            res.append("Output" + str(i + 1) + "_" + line_list[i])
    return res

pin_names = get_ports_info(os.path.join(data_folder, ports_names_file))

Launch Twin Builder

Launch Twin Builder using an implicit declaration and add a new design with the default setup.

project_name = os.path.join(temp_folder.name, "LTI_ROM.aedt")
tb = TwinBuilder(
    project=project_name, version=AEDT_VERSION, non_graphical=NG_MODE, new_desktop=True
)

PyAEDT INFO: Python version 3.10.11 (tags/v3.10.11:7d4cc5a, Apr  5 2023, 00:38:17) [MSC v.1929 64 bit (AMD64)]
PyAEDT INFO: PyAEDT version 0.12.dev0.
PyAEDT INFO: Initializing new Desktop session.
PyAEDT INFO: Log on console is enabled.
PyAEDT INFO: Log on file C:\Users\ansys\AppData\Local\Temp\pyaedt_ansys_2eefa3ca-1776-48e0-bc37-a735794ebc04.log is enabled.
PyAEDT INFO: Log on AEDT is enabled.
PyAEDT INFO: Debug logger is disabled. PyAEDT methods will not be logged.
PyAEDT INFO: Launching PyAEDT with gRPC plugin.
PyAEDT INFO: New AEDT session is starting on gRPC port 52274
PyAEDT INFO: AEDT installation Path C:\Program Files\AnsysEM\v242\Win64
PyAEDT INFO: Ansoft.ElectronicsDesktop.2024.2 version started with process ID 2592.
PyAEDT INFO: Project LTI_ROM has been created.
PyAEDT INFO: No design is present. Inserting a new design.
PyAEDT INFO: Added design 'Twin Builder_F3U' of type Twin Builder.
PyAEDT INFO: Aedt Objects correctly read

Build the LTI ROM with specified configuration file

install_dir = tb.odesktop.GetRegistryString("Desktop/InstallationDirectory")
fitting_exe = os.path.join(install_dir, "FittingTool.exe")
path = '"' + fitting_exe + '"' + "  " + '"t"' + "  " + '"' + data_folder + '"'
process = subprocess.Popen(
    path, stdin=subprocess.PIPE, stdout=subprocess.PIPE, stderr=subprocess.PIPE
)
tb.logger.info("Fitting the LTI ROM training data")
exec = True
startTime = datetime.datetime.now()
execTime = 0.0
while (
    exec and execTime < 60.0
):  # limiting the fitting process execution time to 1 minute
    out, err = process.communicate()
    execTime = (datetime.datetime.now() - startTime).total_seconds()
    if "An LTI ROM has been generated" in str(out):
        process.terminate()
        exec = False

PyAEDT INFO: Fitting the LTI ROM training data

rom_file = ""
model_name_sml = ""

for i in os.listdir(data_folder):
    if i.endswith(".sml"):
        model_name_sml = i.split(".")[0]
        rom_file = os.path.join(data_folder, i)

if os.path.exists(rom_file):
    tb.logger.info("Built intermediate ROM file successfully at: %s", rom_file)
else:
    tb.logger.info("ROM file does not exist at the expected location : %s", rom_file)

PyAEDT INFO: Built intermediate ROM file successfully at: C:\Users\ansys\AppData\Local\Temp\tmpn2xjtr67.ansys\twin_builder\LTI_training\Thermal_ROM_SML.sml

Import the ROM component model

is_created = tb.modeler.schematic.create_component_from_sml(
    input_file=rom_file, model=model_name_sml, pins_names=pin_names
)
os.remove(rom_file)
tb.logger.info("LTI ROM model successfully imported.")

PyAEDT INFO: ModelerCircuit class has been initialized! Elapsed time: 0m 0sec
PyAEDT INFO: ModelerTwinBuilder class has been initialized!
PyAEDT INFO: LTI ROM model successfully imported.

Import the ROM component model in Twin Builder

Place components to create a schematic.

Define the grid distance for ease in calculations

grid_distance = 0.00254

Place the ROM component

rom1 = tb.modeler.schematic.create_component(
    "ROM1", "", model_name_sml, [36 * grid_distance, 28 * grid_distance]
)

Place datapairs blocks for inputs definition

source1 = tb.modeler.schematic.create_component(
    "source1",
    "",
    "Simplorer Elements\\Basic Elements\\Tools\\Time Functions:DATAPAIRS",
    [20 * grid_distance, 29 * grid_distance],
)
source2 = tb.modeler.schematic.create_component(
    "source2",
    "",
    "Simplorer Elements\\Basic Elements\\Tools\\Time Functions:DATAPAIRS",
    [20 * grid_distance, 25 * grid_distance],
)

Import Datasets

data1 = CSVDataset(os.path.join(data_folder, "data1.csv"))
data2 = CSVDataset(os.path.join(data_folder, "data2.csv"))
dataset1 = tb.create_dataset("data1", data1.data["time"], data1.data["input1"])
dataset2 = tb.create_dataset("data2", data2.data["time"], data2.data["input2"])

PyAEDT INFO: Parsing C:/Users/ansys/AppData/Local/Temp/tmpn2xjtr67.ansys/LTI_ROM.aedt.
PyAEDT INFO: File C:/Users/ansys/AppData/Local/Temp/tmpn2xjtr67.ansys/LTI_ROM.aedt correctly loaded. Elapsed time: 0m 0sec
PyAEDT INFO: aedt file load time 0.015559911727905273
PyAEDT INFO: Dataset data1 doesn't exist.
PyAEDT INFO: Dataset $data1 created successfully.
PyAEDT INFO: Dataset data2 doesn't exist.
PyAEDT INFO: Dataset $data2 created successfully.

source1.parameters["CH_DATA"] = dataset1.name
source2.parameters["CH_DATA"] = dataset2.name

tb.modeler.schematic.update_quantity_value(source1.composed_name, "PERIO", "0")

True

tb.modeler.schematic.update_quantity_value(
    source1.composed_name, "TPERIO", "Tend+1", "s"
)

True

tb.modeler.schematic.update_quantity_value(source2.composed_name, "PERIO", "0")

True

tb.modeler.schematic.update_quantity_value(
    source2.composed_name, "TPERIO", "Tend+1", "s"
)

True

Connect components with wires

tb.modeler.schematic.create_wire(
    points=[source1.pins[0].location, rom1.pins[0].location]
)
tb.modeler.schematic.create_wire(
    points=[source2.pins[0].location, rom1.pins[1].location]
)

<ansys.aedt.core.modeler.circuits.object_3d_circuit.Wire at 0x179e70e8e80>

Zoom to fit the schematic

tb.modeler.zoom_to_fit()

Parametrize transient setup

Parametrize the default transient setup by setting the end time and minimum/maximum time steps.

tb.set_end_time("700s")
tb.set_hmin("0.001s")
tb.set_hmax("1s")

True

Solve transient setup

Solve the transient setup.

tb.analyze_setup("TR")

PyAEDT INFO: Key Desktop/ActiveDSOConfigurations/Twin Builder correctly changed.
PyAEDT INFO: Solving design setup TR
PyAEDT INFO: Key Desktop/ActiveDSOConfigurations/Twin Builder correctly changed.
PyAEDT INFO: Design setup TR solved correctly in 0.0h 0.0m 6.0s

True

Get report data and plot using Matplotlib

Get report data and plot it using Matplotlib. The following code gets and plots the values for the inputs and outputs of the LTI ROM.

Units used are based on AEDT default units.

variables_postprocessing = []
pin_names_str = ",".join(pin_names)
rom_pins = pin_names_str.lower().split(",")
fig, ax = plt.subplots(ncols=1, nrows=2, figsize=(18, 7))
fig.subplots_adjust(hspace=0.5)

for i in range(0, 2):
    variable = "ROM1." + rom_pins[i]
    x = tb.post.get_solution_data(variable, "TR", "Time")
    ax[0].plot(
        [el for el in x.intrinsics["Time"]], x.data_real(variable), label=variable
    )

PyAEDT INFO: Post class has been initialized! Elapsed time: 0m 0sec
PyAEDT INFO: Solution Data Correctly Loaded.
PyAEDT INFO: Solution Data Correctly Loaded.

ax[0].set_title("ROM inputs")
ax[0].legend(loc="upper left")

<matplotlib.legend.Legend at 0x179e82aa890>

for i in range(2, 4):
    variable = "ROM1." + rom_pins[i]
    x = tb.post.get_solution_data(variable, "TR", "Time")
    ax[1].plot(
        [el for el in x.intrinsics["Time"]], x.data_real(variable), label=variable
    )

PyAEDT INFO: Solution Data Correctly Loaded.
PyAEDT INFO: Solution Data Correctly Loaded.

ax[1].set_title("ROM outputs")
ax[1].legend(loc="upper left")

<matplotlib.legend.Legend at 0x179ebe4b940>

Show plot

plt.show()

Release AEDT

Release AEDT and close the example.

tb.save_project()
tb.release_desktop()

PyAEDT INFO: Project LTI_ROM Saved correctly
PyAEDT INFO: Desktop has been released and closed.

True

Wait 3 seconds to allow AEDT to shut down before cleaning the temporary directory.

time.sleep(3)

Clean up

All project files are saved in the folder temp_folder.name. If you’ve run this example as a Jupyter notebook, you can retrieve those project files. The following cell removes all temporary files, including the project folder.

temp_folder.cleanup()

---
